AZ845 is a N300 CPE with 4G modem, which maintaining compatibility with IEEE 802.11b/g/n networks.

It’s a SOHO-class network security solution for family home, broadband communications and small SOHO.



Product Features:

  • 1x 10/100MBASE-T Ethernet RJ45 WAN Ports;
  • 3x 10/100MBASE-T Ethernet RJ45 LAN Ports;
  • Support Wi-Fi 2.4G 802.11N 2T2R, speed up to 300Mbps;
  • Support LTE CAT4 with uplink speed up to 50Mbps, and downlink speed up to 150Mbps;

Product Parameters
Download

Chip model MT7628NN+CAT4 LTE Moudle
Memory FLASH 16MB/DDR2 64MB
WiFi Chip Built in MT7628NN
Cellular Frequency LTE-FDD: B1/ 3/ 5/ 8

LTE-TDD: B34/ 38/ 39/ 40/ 41

WCDMA: B1/5/8

WiFi rate 802.11b/g/n Wireless LAN 300Mbps
Interface LAN: 3* 10/100Mbps auto MDI/MDI-X RJ-45 ports

LAN/WAN: 1* 10/100Mbps auto MDI/MDI-X RJ-45 ports

Sim slot: 1*nano sim card

Frequency Band 2.4 GHz frequency band 40MHz
Antennas WIFI 2.4G: 2*5dBi External antennas

LTE: 2*3dBi External antennas

Other: 2* Decorative External antennas

Buttons WPS/Reset
LED Indicators Power NET LAN1 LAN2 LAN3 WAN WIFI LTE
Power Supply DC 12V 1A
Product Size 180X110X35 mm (length X width X height)
Work Environment Working temperature: 0°C-40°C; Working humidity: 5-95%
WAN Connection Support DHCP, PPPoE and Static IP address three internet access models,
Wireless Function WiFi basic function, WiFi advanced function, Guest network,
Wireless Encryption WPA/WPA2, WPA2
Management Function WEB
System Maintenance Device management, Configuration management, Upgrade management, Log function, Status statistics, Restart/reset
Advanced Function Firewall, Virtual server, IPV6, UPnP
Certification CCC,SRRC,CTA certification
