AZ549G Specifications
CPU
Dual-Core ARM Cortex-A55 at 1.0GHz
Chip model
RTL9615C
Memory
NAND FLASH 1Gbit(128MB)/DDR4 4Gbit（512MB）
Bob Driver
GN28L98
PON Protocol Specification
The XGS-PON(10G/10G)ITU-T G.9807.1 MAC supports the following features
Supports data rate of:
~10Gbps(9953 Mbps)downstream.
~10Gbps(9953Mbps) upstream. Up to 256 GEM port-IDs.
Up to 40 AlloclDs.
Ranging and activation process support.
Downstream characteristics:
-Downstream AES-128 encryption and key exchange process.
-Downstream FECRS(248216).
-Dedicated independent queues for PLOAM and CPU packets.
Upstream characteristics:
-Upstream AES-128 encryption and key exchange process.
-Upstream FECRS(248216.)
-Normal queues for PLOAM and CPU.
Support ToD synchronization perITU-TG.9807.1.
Support ONU power saving operation perITU-TG.9807.1.
Network Protocol Specifications
ANSI/IEEE 802.3 NWay auto-negotiation
802.1D bridging
VLAN Translation
IP ToS/DSCP to 802.1p mapping
Class of Service based on UNI, VLAN-ID, 802.1p bit, and combination
Marking/remarking of 802.1p
IGMP v2/v3 snooping and IGMP snooping with proxy report
Broadcast/Multicast rate limiting
802.1Q VLAN tagging/un-tagging
Support flexible traffic classification
Support VLAN Intelligent Bridging and Cross Connect mode
Interface
WAN: 1*10G optical interface (APC)
LAN: 1*10/100/1000/2.5G/5G/10G auto MDI/MDI-X RJ-45 ports
LED Indicators
Power, PON, LOS, INTERNET, 10G LAN
Power Supply
DC12V 1.0A
Security
Firewall, Dos Protection
WAN Networking
Static IP WAN connection
DHCP client WAN connection
PPPoE WAN connection
Management
Standard OMCI (G.988)
Web GUI (HTTP/HTTPS)
Firmware upgrade via FTP/TFTP/HTTP
Telnet, Web, SSH
CLI command via telnet/console
Two-level administration privilege for web configuration
Configuration backup/restore
TR069
Product Size
130X130X36.5mm(length X width X height)
Work Environment
Working temperature: -0°C—40°C
